Closed Loop Stepper Motor With 0.6Nm Nema17

Closed Loop Stepper Motor With 0.6Nm Nema17

Another model in Nema17 size,with 0.6Nm output torque,8mm motor shaft,76mm motor length,4 lead wire,2.3A current,3VDC rated voltage,it is best for machines such as winding machine

Product Details:


Product Introduction:Closed loop stepper motor with 0.6Nm Nema17


Another model in Nema17 size,with 0.6Nm output torque,8mm motor shaft,76mm motor length,4 lead wire,2.3A current,3VDC rated voltage,it is best for machines such as winding machine .


Motor Dimension:Closed loop stepper motor with 0.6Nm Nema17


Motor Encoder Wiring Defination(DB15PIN male)


Motor encoder outlet definition(DB15   Pin male connector)

PIN

Cable Color

Definition

1

blue/black

EA+

2

red

VCC

3

Red/white

GND

11

Green/black

EB+

12

green

EB-

13

blue

EA-




Product Technical Data:Closed loop stepper motor with 0.6Nm Nema17

Model

Holding

Torque(NM)

Current

/Phase(A)

Resistance

(Ω)

Inductance

(MH)

Rotary Nertia

(g.cm²)

Length

(MM)

Weight

(Kg)

Matched Drive

TC42-06

  0.6

   2.3

1.3

   2.5

    86

  76

 0.45

TS808D

Product Technique Feature:Closed loop stepper motor with 0.6Nm Nema17

TC42-06  Specification

Accuracy

±5%(full stepunload)

Temperature

50 MAX

Environment

-20~+50

Insulation   Resistance

100MΩmin 500VDC

Pressure

500VAC for one   minute

Radial runout

0.02   Max(450g-load)

Axial runout

0.08   Max(450g-load)


Motor Wiring


Product Service:Closed loop stepper motor with 0.6Nm Nema17

ECON provide technical service from start to end,and offer one year warranty after customer receive products. Any question,send e-mail to our technical engineer and sales,or directly chat with us by skype.


Payment and Delivery:Closed loop stepper motor with 0.6Nm Nema17

ECON supports T/T,Paypal,Western Union to make payment. We can arrange express,air and sea shipment,we have professional team to deal with logistic.
